| Energy Class (ft lbs) | 16,000 |
|---|---|
| Operation Weight (kgs) | 3,900 |
| Operation Weight (lbs) | 8,599 |
| Hose Length (Inches) | 1.625" x 112" |
| Operating Pressure (Kg/cm^2) | 160~190 |
| Operating Pressure (psi) | 2,276~2,702 |
| Tool Diameter (mm) | 175 |
| Tool Diameter (inches) | 6.88 |
| 2nd Relief Setting Pressure (Kg/cm^2) | 230 |
| 2nd Relief Setting Pressure (psi) | 3,300 |
| Required Oil Flow (LPM) | 240~320 |
| Required Oil Flow (GPM) | 63.4~84.5 |
| Blow Rate (Long Stroke BPM) | 230~330 |
| Blow Rate (Short Stroke BPM) | 270~500 |
| Accumulator Gas Pressure (Kg/cm^2) | 55~60 |
| Accumulator Gas Pressure (psi) | 780~850 |
| Suitable Carrier (tons) | 40~60 |
| Suitable Application | Mid and Large Excavators |
