| Energy Class (ft lbs) | 2,800 |
|---|---|
| Operation Weight (kgs) | 1,170 |
| Operation Weight (lbs) | 2,580 |
| Hose Length (Inches) | .75" x 100" |
| Operating Pressure (Kg/cm^2) | 160~190 |
| Operating Pressure (psi) | 2,276~2,702 |
| Tool Diameter (mm) | 115 |
| Tool Diameter (inches) | 4.52 |
| 2nd Relief Setting Pressure (Kg/cm^2) | 210 |
| 2nd Relief Setting Pressure (psi) | 3,000 |
| Required Oil Flow (LPM) | 90~130 |
| Required Oil Flow (GPM) | 23.7~34.3 |
| Blow Rate (Long Stroke BPM) | 320~550 |
| Blow Rate (Short Stroke BPM) | 400~700 |
| Accumulator Gas Pressure (Kg/cm^2) | 55~60 |
| Accumulator Gas Pressure (psi) | 780~850 |
| Suitable Carrier (tons) | 12~18 |
| Suitable Application | Mid and Large Excavators |
